Product Description – C10F3TM100
Circuit Breaker – ComPacT NSX100F
Key Features:
- Model: ComPacT NSX100F
- Product Code: C10F3TM100
- Breaking Capacity: 36kA at 415V AC
- Number of Poles: 3
- Trip Unit: TMD (Thermal Magnetic Trip Unit)
- Rated Current: 100A
- Voltage Rating: 415V AC
- Mounting: Fixed
- Standards Compliance: IEC 60947-2, IEC 60947-1
- Application: Suitable for industrial and commercial applications, providing reliable protection against overloads and short circuits.
Detailed Features:
- Compact Design: Space-saving design for efficient panel installation.
- High Breaking Capacity: Ensures reliable protection in demanding environments.
- TMD Trip Unit: Provides precise thermal and magnetic protection for overloads and short circuits.
- Easy Installation: Simplified mounting and wiring for quick setup.
- Durability: Robust construction ensures long-lasting performance in harsh conditions.
- Safety: Complies with international safety standards for reliable operation.
- Versatility: Suitable for a wide range of applications, including motor protection, distribution, and feeder protection.
Technical Specifications:
| Parameter | Value |
|---|---|
| Rated Current (In) | 100A |
| Rated Voltage (Ue) | 415V AC |
| Breaking Capacity (Icu) | 36kA |
| Number of Poles | 3 |
| Trip Unit Type | TMD (Thermal Magnetic) |
| Mounting Type | Fixed |
| Standards | IEC 60947-2, IEC 60947-1 |
Applications:
The ComPacT NSX100F circuit breaker is ideal for use in:
- Industrial control panels
- Commercial buildings
- Motor protection circuits
- Distribution boards
- Feeder protection
Additional Information:
This circuit breaker is part of Schneider Electric’s ComPacT NSX range, known for its reliability, performance, and ease of use. It is designed to meet the needs of modern electrical installations, providing superior protection and safety.
