Product Description – LV510956 | EasyPact CVS100BS

Overview

The EasyPact CVS100BS is a high-performance circuit breaker designed by Schneider Electric. It is part of the EasyPact CVS range, known for its reliability and efficiency in protecting electrical circuits. This model is specifically designed for applications requiring a 63 A rating and a breaking capacity of 25 kA at 415 VAC.

Key Features

• Model: EasyPact CVS100BS
• Rated Current: 63 A
• Breaking Capacity: 25 kA at 415 VAC
• Trip Unit: Thermal Magnetic TM-D
• Number of Poles: 4P (4 Poles)
• Mounting: 3D (Three-Phase with Neutral)
• Voltage Rating: 415 VAC
• Standards Compliance: IEC 60947-2
• Application: Suitable for industrial, commercial, and residential applications

Detailed Features

Thermal Magnetic TM-D Trip Unit

The TM-D trip unit provides reliable protection against overloads and short circuits. It combines both thermal and magnetic protection mechanisms:

• Thermal Protection: Protects against overloads by responding to prolonged overcurrent conditions.
• Magnetic Protection: Provides instantaneous protection against short circuits.

4P 3D Configuration

The 4P (4 Poles) configuration includes three phases and a neutral, making it suitable for three-phase systems where neutral protection is required. The 3D mounting ensures easy installation and compatibility with standard electrical panels.

High Breaking Capacity

With a breaking capacity of 25 kA at 415 VAC, the EasyPact CVS100BS can handle high fault currents, ensuring the safety and reliability of the electrical system.

Robust Design

The circuit breaker is designed to withstand harsh environmental conditions, making it suitable for a wide range of applications. Its compact design allows for easy integration into existing electrical systems.

Standards Compliance

The EasyPact CVS100BS complies with the IEC 60947-2 standard, ensuring high performance and safety in line with international electrical standards.

Applications

The EasyPact CVS100BS is ideal for use in:

• Industrial plants
• Commercial buildings
• Residential complexes
• Data centers
• HVAC systems

Conclusion

The EasyPact CVS100BS circuit breaker from Schneider Electric offers a reliable and efficient solution for protecting electrical circuits. With its high breaking capacity, thermal magnetic trip unit, and robust design, it is well-suited for a variety of applications, ensuring safety and performance in electrical systems.
