LC2K1201M7 | TeSys K Reversing Contactor

Product Overview

The LC2K1201M7 is a TeSys K reversing contactor from Schneider Electric, designed for controlling the direction of three-phase motors. It is suitable for applications requiring frequent start-stop operations and reversing motor direction.

Key Features

• Type: Reversing Contactor
• Number of Poles: 3P (3 Poles)
• Rated Operational Voltage (Ue): AC-3 ≤ 440 V
• Rated Operational Current (Ie): 12 A
• Auxiliary Contacts: 1 Normally Closed (1 NC)
• Coil Voltage: 220…230 V AC
• Mounting: Screw Mounting
• Mechanical Durability: Up to 10 million operations
• Electrical Durability: Up to 1 million operations
• Enclosure: IP20 (Finger-safe)
• Compliance: IEC/EN 60947-4-1, UL 60947-4-1
• Dimensions: Compact design for space-saving installation
• Weight: Lightweight for easy handling

Applications

The LC2K1201M7 is ideal for use in:

• Industrial machinery
• Conveyor systems
• Pumps and fans
• Material handling equipment
• Other applications requiring motor reversing

Benefits

• High reliability and durability
• Compact and modular design
• Easy installation and maintenance
• Compatible with TeSys K accessories
• Safe and efficient motor control

Additional Information

For more details, refer to the product datasheet or contact Schneider Electric support.
