29364 | INTERFACE FOR AU TO MATIC CONTROLLER AC – Schneider Electric

Name: 29364 - ACP control plate, Transferpact, 380 VAC to 415 VAC 50/60Hz | Schneider Electric
Brand: Schneider Electric
SKU: 29364
Price: 15464.52 INR
Availability: BackOrder

SKU: 29364

Original price was: ₹28,638.00.Current price is: ₹15,464.52. Excl. GST

Dispatch By : 15 Weeks

20 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

Specifications

Main
Range of product	Compact NS630b…1600 NSX400…630 Compact NS100…630 MasterPact NW MasterPact NT NSX100…250
Range	ComPact
Product or component type	Control plate
Accessory / separate part category	Interlocking accessory
Range compatibility	ComPact ComPact NS circuit breaker ComPact ComPact NSX circuit breaker Masterpact MasterPact NT circuit breaker Masterpact MasterPact NT switch disconnector Masterpact MasterPact NW circuit breaker Masterpact MasterPact NW switch disconnector
Device short name	ACP
[Us] rated supply voltage	380…415 V AC at 50/60 Hz 440 V AC at 60 Hz
Complementary
Interlocked device	MasterPact NW NSX400…630 NSX100…250 Compact NS630b…1600 Compact NS100…630 MasterPact NT
Selection modes	Circuit breaker on N Circuit breaker on R
Input type	Contacts customer voluntary order to transfer to source R
Output type	Contacts customer: indication of operation in automatic or stop mode
Product compatibility	Compact NSX400…630 Compact NSX100…250 Compact NS630b…1600
Environment
IP degree of protection	IP20 connectors: conforming to EN 60529 IP40 front: conforming to EN 60529 IP30 side: conforming to EN 60529
IK degree of protection	Front: IK07 conforming to EN 50102
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	12.400 cm
Package 1 Width	16.400 cm
Package 1 Length	27.900 cm
Package 1 Weight	2.527 kg
Unit Type of Package 2	S04
Number of Units in Package 2	6
Package 2 Height	30.000 cm
Package 2 Width	40.000 cm
Package 2 Length	60.000 cm
Package 2 Weight	15.860 kg
Contractual warranty
Warranty (in months)	18
