2CDS253001R0804 | S203-C80 MCB C-Char., 6kA, 80A, 3P – ABB

Name: 2CDS253001R0804 | S203-C80 MCB C-Char., 6kA, 80A, 3P - ABB - myelectric.in
Brand: ABB
SKU: 2CDS253001R0804
Price: 4504.00 INR
Availability: InStock

SKU: 2CDS253001R0804

Original price was: ₹11,260.00.Current price is: ₹4,504.00. Excl. GST

14 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

Sourced through authorised channels, the ABB 2CDS253001R0804 miniature circuit breaker (mcb) delivers dependable performance for reliable circuit protection and isolation. Key ratings include 80 A, 3 Poles. myelectric.in stocks the 2CDS253001R0804 | S203-C80 MCB C-Char., 6kA, 80A, 3P for contractors, panel builders, and project buyers — buy online with GST invoice, or request a bulk quote for domestic supply and export to UAE, Singapore, UK, USA, Sri Lanka and more.

📋 Technical Specifications

Parameter	Value
Brand	ABB
Part Number / SKU	2CDS253001R0804
Category	Miniature Circuit Breaker (MCB)
Current Rating	80 A
Poles	3 Poles
Breaking Capacity	6 kA
Rated Voltage	230/400V AC
Rated Frequency	50/60 Hz
Trip Mechanism	Thermal-magnetic (bimetal overload + electromagnetic short-circuit)
Mounting	35mm DIN rail (EN 60715)
Width	54 mm (3 × 18mm modules)
Electrical Endurance	≥ 20,000 operating cycles (per IEC 60898-1)
Pollution Degree	3 (per IEC 60664-1)
Standard	IS 8828 / IEC 60898-1 (residential) and IEC 60947-2 (industrial)
Certifications	BIS certified, CE, KEMA tested

⚡ Key Features

Protects circuits at 80 A with 6 kA short-circuit breaking capacity — rated for residential and commercial final circuits.
3 Poles — protects a three-phase circuit without neutral; fits standard 35mm DIN rail in distribution boards.
Thermal-magnetic trip mechanism — bimetal element trips on sustained overload, instantaneous magnetic trip on short-circuit; two independent protection functions in one compact module.
Manufactured to IS 8828 / IEC 60898-1 (residential) and IEC 60947-2 (industrial) — complies with the applicable Indian BIS and IEC international standards for this product category.
BIS certified, CE, KEMA tested — meets Indian regulatory requirements for use in government, commercial, and industrial electrical installations.
Genuine authorised ABB product — sourced directly from the official distribution network with full manufacturer traceability and warranty.
GST invoice provided for India orders — valid for corporate procurement, government project orders, and public tender supply via myelectric.in.
Worldwide export available — UAE, Singapore, UK, USA, Sri Lanka & more. Contact +91 94814 00316 for bulk pricing and international shipping.

❓ Frequently Asked Questions

Q: What load can the 2CDS253001R0804 protect at its rated 80 A?

A: The 2CDS253001R0804 is rated to carry and protect circuits up to 80 A continuously. For motor loads, ensure the full-load current (FLC) of the motor does not exceed this rating. For resistive loads (heaters, lighting), the 80 A rating is used directly. Derate by 20% for ambient temperatures above 40°C.

Q: What does the 6 kA breaking capacity on the 2CDS253001R0804 mean in practice?

A: Breaking capacity (6 kA) is the maximum prospective short-circuit current the 2CDS253001R0804 can safely interrupt without damage. Before installing, verify that the prospective fault level at the installation point does not exceed 6 kA — this is checked using a fault level calculation or from the upstream transformer impedance data. Installing a breaker with insufficient breaking capacity is a serious safety violation.

Q: Is the 2CDS253001R0804 suitable for both single-phase and three-phase systems?

A: The 2CDS253001R0804 with 3 Poles can protect three-phase circuits. Each pole simultaneously interrupts one phase — ensuring all phases are de-energised on a fault.

Q: Can the 2CDS253001R0804 be DIN rail mounted in any standard distribution board?

A: Yes. This ABB MCB uses the standard 35mm EN 60715 DIN rail and 17.5mm module width, making it compatible with all major brand distribution boards and enclosures. Terminal capacity accommodates both rigid and flexible conductors up to the rated cross-section.

Q: What happens when the 2CDS253001R0804 trips — how do I identify and reset it?

A: When the 2CDS253001R0804 trips on fault, the handle moves to a midway position (between ON and OFF), distinctly visible from a distance. To reset: (1) identify and rectify the fault, (2) push the handle fully to OFF, (3) then switch back to ON. Never force-reset without investigating the fault cause.
