31110 SWITCH INS400 3P. Schneider Electric Image
Click to enlarge

    31110 | SWITCH INS400 3P. – Schneider Electric

    SKU: 31110

    Original price was: ₹62,040.00.Current price is: ₹51,183.00. Excl. GST

    Out of stock

    Out of stock

    20 People watching this product now!

    Order protection

    Buy with complete confidence.

    We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

    Buyer protection on every order
    Global DeliveryShipped pan-India and to export markets.
    On-Time DeliveryPacked and dispatched on schedule.
    100% OriginalFrom brand-authorised channels only.
    GST InvoiceCompliant, ITC-ready tax invoice.
    Secure PaymentEncrypted, trusted payment gateways.
    Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

    Additional Addons/Accessories

    29450 standard auxiliary contact, circuit breaker status OF-SD-SDE-SDV, 1 single contact Schneider Electric 29450 main image
    -48%

    29450 | standard auxiliary contact, circuit breaker status OF-SD-SDE-SDV, 1 single contact – Schneider Electric

    Schneider Electric
    Original price was: ₹1,640.00.Current price is: ₹852.80. Excl. GST
    Add to basket
    SKU: 29450
    -46%

    LV432594 | 1 4P LONG TERMINAL SHIELD – Schneider Electric

    Schneider Electric
    Original price was: ₹2,320.00.Current price is: ₹1,252.80. Excl. GST
    Add to basket
    SKU: LV432594
    -46%

    LV432490 | 3P SPREADER (52.5MM) PH BARRIERS INV/IN – Schneider Electric

    Schneider Electric
    Original price was: ₹5,520.00.Current price is: ₹2,980.80. Excl. GST
    Add to basket
    SKU: LV432490
    LV432570 interphase barriers, Compact NSX 400 630, EasyPact CVS 400 630, set of 6 parts Schneider Electric odalv432570 1500x1
    -46%

    LV432570 | interphase barriers, Compact NSX 400/630, EasyPact CVS 400/630, set of 6 parts – Schneider Electric

    Schneider Electric
    Original price was: ₹1,550.00.Current price is: ₹837.00. Excl. GST
    Add to basket
    SKU: LV432570
    -46%

    LV432592 | 1 4P SHORT TERMINAL SHIELD – Schneider Electric

    Schneider Electric
    Original price was: ₹1,480.00.Current price is: ₹799.20. Excl. GST
    Add to basket
    SKU: LV432592

      Sourced through authorised channels, the Schneider Electric 31110 switch from the ComPact range delivers dependable performance for everyday wiring and control. Key ratings include AC-22A: 400 A AC 50/60 Hz 220/240 V, 125 V DC, 3P. myelectric.in stocks the SWITCH INS400 3P. for contractors, panel builders, and project buyers — buy online with GST invoice, or request a bulk quote for domestic supply and export to UAE, Singapore, UK, USA, Sri Lanka and more.

      📋 Technical Specifications

      Product
      BrandSchneider Electric
      Part Number / SKU31110
      CategorySwitch
      Main
      RangeComPact
      Product or component typeSwitch disconnector
      Product nameComPacT INS
      Poles description3P
      Network typeAC
      DC
      Network frequency50/60 Hz
      [Ie] rated operational currentAC-22A: 400 A AC 50/60 Hz 220/240 V
      AC-22A: 400 A AC 50/60 Hz 380/415 V
      AC-22A: 400 A AC 50/60 Hz 440/480 V
      AC-22A: 400 A AC 50/60 Hz 480 V NEMA
      AC-22A: 400 A AC 50/60 Hz 500/525 V
      AC-22A: 400 A AC 50/60 Hz 660/690 V
      AC-23A: 400 A AC 50/60 Hz 220/240 V
      AC-23A: 400 A AC 50/60 Hz 380/415 V
      AC-23A: 400 A AC 50/60 Hz 440/480 V
      AC-23A: 400 A AC 50/60 Hz 480 V NEMA
      AC-23A: 400 A AC 50/60 Hz 500/525 V
      AC-23A: 400 A AC 50/60 Hz 660/690 V
      DC-22A: 400 A DC 125 V 2 poles in series
      DC-23A: 400 A DC 125 V 2 poles in series
      [Ui] rated insulation voltage800 V AC 50/60 Hz
      [Uimp] rated impulse withstand voltage8 kV
      8 kV conforming to IEC 60947-3
      [Ith] conventional free air thermal current400 A at 60 °C
      [Icm] rated short-circuit making capacity330 kA with upstream protection circuit breaker 690 V AC at 50/60 Hz
      50 kA switch-disconnector alone 690 V AC at 50/60 Hz
      [Ue] rated operational voltage125 V DC
      690 V AC 50/60 Hz
      Suitability for isolationYes
      Contact position indicatorYes
      Visible breakNo
      Pollution degree3
      Complementary
      Control typeDirect front rotary handle
      Handle colourBlack
      Mounting modeFixed
      Mounting supportPlate
      Rail
      Upside connectionFront
      Downside connectionFront
      Maximum powerAC-23: 110 kW at 220/240 V AC 50/60 Hz
      AC-23: 110 kW at 230 V AC 50/60 Hz (NEMA)
      AC-23: 200 kW at 380/415 V AC 50/60 Hz
      AC-23: 220 kW at 440 V AC 50/60 Hz
      AC-23: 220 kW at 480 V AC 50/60 Hz (NEMA)
      AC-23: 250 kW at 500/525 V AC 50/60 Hz
      AC-23: 400 kW at 660/690 V AC 50/60 Hz
      Rated dutyUninterrupted
      [Icw] rated short-time withstand current11.5 kA during 3 s conforming to IEC 60947-3
      20 kA during 1 s conforming to IEC 60947-3
      4 kA during 30 s conforming to IEC 60947-3
      4.9 kA during 20 s conforming to IEC 60947-3
      Mechanical durability10000 cycles
      Electrical durabilityAC-22A: 1500 cycles 440 V AC 50/60 Hz
      AC-22A: 1500 cycles 500 V AC 50/60 Hz
      AC-22A: 1500 cycles 690 V AC 50/60 Hz
      AC-23A: 1500 cycles 440 V AC 50/60 Hz
      AC-23A: 1500 cycles 500 V AC 50/60 Hz
      AC-23A: 1500 cycles 690 V AC 50/60 Hz
      DC-23A: 1000 cycles 125 V DC 2 poles in series
      Connection pitch45 mm
      Height205 mm
      Width185 mm
      Depth120 mm
      Product weight4.6 kg
      Environment
      StandardsIEC 60947-1
      IEC 60947-3
      Product certificationsKEMA-KEUR
      CCC
      IP degree of protectionIP40 conforming to IEC 60529
      IK degree of protectionIK07 conforming to EN 50102
      Ambient air temperature for operation-25…70 °C
      Ambient air temperature for storage-50…85 °C
      Packing Units
      Unit Type of Package 1PCE
      Number of Units in Package 11
      Package 1 Height19.000 cm
      Package 1 Width19.000 cm
      Package 1 Length22.600 cm
      Package 1 Weight4.985 kg
      Unit Type of Package 2S04
      Number of Units in Package 24
      Package 2 Height30.000 cm
      Package 2 Width40.000 cm
      Package 2 Length60.000 cm
      Package 2 Weight20.639 kg
      Unit Type of Package 3P12
      Number of Units in Package 316
      Package 3 Height50.000 cm
      Package 3 Width80.000 cm
      Package 3 Length120.000 cm
      Package 3 Weight93.757 kg
      Contractual warranty
      Warranty (in months)18

      ⚡ Key Features

      • Manufactured to IS/IEC 60947, IS 8828 (MCBs), IS 13947, IEC 61439 (DBs) — complies with Indian BIS and IEC international safety standards.
      • BIS certified, CE marked, RoHS compliant — meets Indian regulatory requirements for use in government, commercial, and industrial electrical installations.
      • Genuine authorised Schneider Electric product — sourced directly from the official distribution network with full manufacturer traceability and warranty.
      • GST invoice provided for India orders — valid for corporate procurement, government project orders, and public tender supply via myelectric.in.
      • Worldwide export available — UAE, Singapore, UK, USA, Sri Lanka & more. Contact +91 94814 00316 for bulk pricing and international shipping.
