Product Description – 3VM14635GE420AA0

Siemens MCCB 630 A, 4 Pole, 55 kA, Adjustable O/L & Fixed S/C Settings, Thermal Magnetic Trip Unit (ATFM)

Key Features:

• Product Code: 3VM14635GE420AA0
• Type: Molded Case Circuit Breaker (MCCB)
• Rated Current: 630 A
• Number of Poles: 4 Pole
• Breaking Capacity: 55 kA
• Trip Unit: Thermal Magnetic Trip Unit (ATFM)
• Overload Protection: Adjustable
• Short-Circuit Protection: Fixed Settings
• Mounting: Fixed Type
• Standards Compliance: IEC 60947-2
• Application: Suitable for industrial and commercial applications requiring reliable circuit protection.

Detailed Features:

• Thermal Magnetic Trip Unit (ATFM): Provides reliable protection against overloads and short circuits. The thermal element protects against overloads, while the magnetic element ensures quick response to short circuits.
• Adjustable Overload Protection: Allows customization of the overload protection settings to match specific application requirements.
• Fixed Short-Circuit Settings: Ensures consistent and reliable short-circuit protection without the need for manual adjustments.
• High Breaking Capacity: With a breaking capacity of 55 kA, this MCCB is capable of interrupting high fault currents, ensuring safety and reliability in demanding environments.
• Robust Construction: Designed for durability and long service life, even in harsh industrial environments.
• Easy Installation: Fixed mounting type simplifies installation and reduces setup time.
• Compliance with International Standards: Meets the requirements of IEC 60947-2, ensuring high performance and safety.

Applications:

• Industrial plants and machinery
• Commercial buildings and infrastructure
• Power distribution systems
• Motor control centers
• Any application requiring reliable circuit protection and high breaking capacity

Technical Specifications:

Additional Information:

The Siemens 3VM14635GE420AA0 MCCB is a high-performance circuit breaker designed to provide reliable protection for electrical circuits in industrial and commercial applications. With its adjustable overload protection and fixed short-circuit settings, it offers flexibility and safety in a wide range of scenarios. The thermal magnetic trip unit ensures quick and accurate response to both overloads and short circuits, making it an ideal choice for demanding environments.
