500A 4P 50KA TM Optium 1.0 Fixed F4 MCCB – Indoasian

The 500A 4P 50KA TM Optium 1.0 Fixed F4 MCCB by Indoasian is a high-performance molded case circuit breaker designed for reliable and efficient electrical protection in industrial and commercial applications. This MCCB is part of the Optium 1.0 series, known for its advanced features and robust construction.

Key Features:

• Rated Current: 500A
• Number of Poles: 4P (Four Poles)
• Breaking Capacity: 50KA (50,000 Amperes)
• Type: Thermal Magnetic (TM)
• Mounting Type: Fixed
• Series: Optium 1.0
• Frame Size: F4

Applications:

This MCCB is ideal for protecting electrical circuits from overloads, short circuits, and other electrical faults. It is suitable for use in:

• Industrial plants
• Commercial buildings
• Power distribution systems
• HVAC systems
• Motor control centers

Technical Specifications:

• Voltage Rating: Up to 690V AC
• Frequency: 50/60 Hz
• Operating Temperature: -5°C to +40°C
• Standards Compliance: IEC 60947-2, IS/IEC 60947-2
• Terminal Type: Screw-type terminals for secure connections

Design and Construction:

The 500A 4P 50KA TM Optium 1.0 Fixed F4 MCCB is built with high-quality materials to ensure durability and long service life. Its compact design allows for easy installation in tight spaces, while the thermal-magnetic trip unit provides precise and reliable protection.

Safety Features:

• Overload and short-circuit protection
• High breaking capacity for enhanced safety
• Arc quenching technology for reduced arc flash hazards

Why Choose Indoasian Optium 1.0 MCCB?

Indoasian is a trusted name in electrical protection devices, and the Optium 1.0 series is designed to meet the highest standards of performance and reliability. This MCCB offers excellent protection, ease of use, and compliance with international standards, making it a preferred choice for professionals.
