50A 3P 25KA TM Optium 1.0 Fixed F1 MCCB – Indoasian

The 50A 3P 25KA TM Optium 1.0 Fixed F1 MCCB by Indoasian is a high-performance molded case circuit breaker designed for reliable and efficient electrical protection. This MCCB is ideal for industrial, commercial, and residential applications, ensuring safety and durability in electrical systems.

Key Features:

• Rated Current: 50A
• Number of Poles: 3P (Three Poles)
• Breaking Capacity: 25KA (25,000 Amperes)
• Thermal Magnetic Trip Unit: TM (Thermal Magnetic)
• Series: Optium 1.0
• Mounting Type: Fixed
• Fault Protection: F1 (Short Circuit Protection)
• Brand: Indoasian

Applications:

This MCCB is suitable for a wide range of applications, including:

• Industrial electrical distribution systems
• Commercial buildings and offices
• Residential complexes
• Power distribution panels
• Motor control centers

Technical Specifications:

• Rated Voltage: 415V AC
• Frequency: 50/60Hz
• Operating Temperature: -5°C to +40°C
• Storage Temperature: -25°C to +70°C
• Standards: IEC 60947-2, IS/IEC 60947-2
• Terminal Type: Screw Type
• Enclosure Material: Thermoplastic, Flame Retardant

Advantages:

• High breaking capacity ensures reliable protection against short circuits.
• Thermal magnetic trip unit provides precise overload and short circuit protection.
• Compact and robust design for easy installation and long-lasting performance.
• Complies with international safety standards for enhanced reliability.
• Ideal for both new installations and retrofitting in existing systems.

Package Includes:

• 1 x 50A 3P 25KA TM Optium 1.0 Fixed F1 MCCB
• User Manual

Warranty:

The product comes with a standard warranty of 12 months from the date of purchase, subject to terms and conditions.

Product Data Sheet
