5SY71068CC | Betagard MCB 6 A, 1 Pole, 15 kA, D-Curve – Siemens

Product Overview

The 5SY71068CC is a Betagard Miniature Circuit Breaker (MCB) from Siemens, designed for reliable protection of electrical circuits. It is a 1-pole MCB with a rated current of 6 A, a breaking capacity of 15 kA, and a D-curve tripping characteristic, making it suitable for a wide range of applications.

Key Features

• Rated Current: 6 A
• Number of Poles: 1 Pole
• Breaking Capacity: 15 kA
• Tripping Characteristic: D-Curve
• Voltage Rating: 230/400 V AC
• Mounting Type: DIN Rail Mounting
• Standards Compliance: IEC/EN 60898-1, IEC/EN 60947-2
• Terminal Type: Screw Clamp
• Operating Temperature: -25°C to +55°C
• Mechanical Life: 20,000 Operations
• Electrical Life: 10,000 Operations
• Protection Class: IP20
• Weight: Approx. 0.1 kg

Applications

The 5SY71068CC MCB is ideal for use in residential, commercial, and industrial environments. It provides reliable protection against overloads and short circuits, ensuring the safety of electrical installations and connected equipment.

Advantages

• High breaking capacity ensures reliable protection in demanding conditions.
• D-Curve tripping characteristic is suitable for circuits with high inrush currents, such as those with motors or transformers.
• Compact design allows for easy installation in distribution boards.
• Compliance with international standards guarantees safety and reliability.

Dimensions

• Width: 17.5 mm
• Height: 80 mm
• Depth: 70 mm

Safety Information

Always ensure that the installation and maintenance of this MCB are carried out by a qualified electrician in accordance with local regulations and standards.
