AC-S2E-02 | Serial to Ethernet Converter – Selec
The AC-S2E-02 is a high-performance Serial to Ethernet Converter designed by Selec to bridge the gap between serial devices and Ethernet networks. This compact and reliable device allows seamless integration of legacy serial equipment into modern Ethernet-based systems, enabling remote access and control over IP networks.
Key Features
- Serial Interface: Supports RS-232/RS-485/RS-422 serial communication protocols.
- Ethernet Connectivity: 10/100 Mbps Ethernet port for fast and reliable network integration.
- Power Supply: Wide input voltage range (12-48V DC) for flexible installation.
- Compact Design: DIN rail mountable for easy installation in industrial environments.
- Configuration Options: Web-based configuration interface for easy setup and management.
- Data Transmission: Supports TCP Server, TCP Client, UDP, and Virtual COM modes.
- LED Indicators: Status LEDs for power, Ethernet, and serial communication for quick diagnostics.
- Operating Temperature: Wide operating temperature range (-10°C to 60°C) for harsh environments.
- Security: Built-in firewall and password protection for secure data transmission.
- Compatibility: Compatible with a wide range of industrial devices and software applications.
Applications
The AC-S2E-02 is ideal for use in various industries, including:
- Industrial automation
- Building management systems
- Remote monitoring and control
- Energy management systems
- Retail and hospitality
Technical Specifications
| Parameter | Specification |
|---|---|
| Serial Interface | RS-232/RS-485/RS-422 |
| Ethernet Interface | 10/100 Mbps, RJ45 |
| Power Supply | 12-48V DC |
| Operating Temperature | -10°C to 60°C |
| Dimensions | 90mm x 70mm x 25mm |
| Weight | 200g |
Package Contents
- 1 x AC-S2E-02 Serial to Ethernet Converter
- 1 x Power Adapter (optional)
- 1 x Mounting Kit
- 1 x User Manual
Product Data Sheet
