Schneider Electric NSX100F 18kA AC-DC 2P 63A TMD (C10F2TM063)
Product Overview
The Schneider Electric NSX100F is a high-performance, compact circuit breaker designed for reliable protection in commercial and industrial applications. This 2-pole model features a thermal-magnetic trip unit (TMD) with a 63A current rating and an impressive 18kA breaking capacity for both AC and DC circuits.
Key Features
- Model: NSX100F
- Part Number: C10F2TM063
- Poles: 2P (2-Pole)
- Rated Current: 63A
- Breaking Capacity: 18kA (AC/DC)
- Trip Unit: Thermal-Magnetic (TMD)
- Mounting: Fixed type
- Standards: IEC 60947-2, CE certified
- Terminals: Screw-type for secure connections
Applications
Ideal for:
- Commercial building electrical distribution
- Industrial control panels
- Machine protection
- Solar PV systems (DC applications)
- Motor protection circuits
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Operational Voltage (Ue) | 440V AC / 250V DC |
| Rated Insulation Voltage (Ui) | 690V |
| Rated Impulse Withstand Voltage (Uimp) | 6kV |
| Operating Temperature Range | -25°C to +60°C |
| Mechanical Durability | 20,000 operations |
| Electrical Durability | 10,000 operations |
Why Choose Schneider Electric NSX100F?
- Reliable protection against short-circuits and overloads
- Compact design saves panel space
- High breaking capacity for demanding applications
- Dual AC/DC rating for versatile applications
- Global Schneider Electric quality and support
Package Includes
- 1 x Schneider Electric NSX100F 2P 63A TMD Circuit Breaker
- Product documentation
Note: Accessories such as auxiliary contacts, shunt trips, and undervoltage releases are available separately.
