Schneider Electric NSX100F 36kA AC 3P3D 100A 6.2E (C10F36E100)
Product Overview
The Schneider Electric NSX100F is a high-performance molded case circuit breaker (MCCB) designed for reliable protection in industrial and commercial electrical installations. With a breaking capacity of 36kA, this 3-pole breaker ensures safety and efficiency in demanding electrical environments.
Key Features
- Model: NSX100F
- Current Rating: 100A
- Breaking Capacity: 36kA at 415V AC
- Number of Poles: 3P3D (3 Poles, 3 Protected Poles)
- Tripping Unit: Micrologic 6.2E (Electronic)
- Mounting: Fixed Type
- Standards Compliance: IEC 60947-2
- Terminal Type: Front or Rear Connection
Applications
Ideal for protecting electrical circuits in:
- Industrial plants
- Commercial buildings
- Data centers
- Infrastructure projects
- HVAC systems
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Current (In) | 100A |
| Rated Voltage (Ue) | 415V AC |
| Rated Insulation Voltage (Ui) | 690V AC |
| Short Circuit Breaking Capacity (Icu) | 36kA at 415V AC |
| Tripping Unit Type | Micrologic 6.2E (Electronic) |
| Protection Functions | Overload (Ir), Short Circuit (Im), Ground Fault (Ig) |
Why Choose Schneider Electric NSX100F?
- High breaking capacity for enhanced safety
- Precise electronic protection with Micrologic 6.2E
- Compact design saves panel space
- Easy installation and maintenance
- Reliable performance in harsh environments
Note: For complete technical details and installation instructions, please refer to the manufacturer’s datasheet.
Available at: myelectric.in | Your trusted partner for quality electrical components.
