Schneider Electric NSX100F 36kA AC 4P3D 25A TMD MCCB (C10F6TM025)
Product Description
The Schneider Electric NSX100F is a high-performance Molded Case Circuit Breaker (MCCB) designed for reliable protection of electrical circuits against overloads and short circuits. With a breaking capacity of 36kA, this 4-pole (4P) breaker with 3 protected poles (3D) and 25A current rating ensures superior safety for industrial and commercial applications.
Key Features
- Model: NSX100F
- Reference: C10F6TM025
- Breaking Capacity: 36kA at 415V AC
- Number of Poles: 4P (4 Poles) with 3D (3 Protected Poles)
- Rated Current: 25A
- Trip Unit: Thermal Magnetic (TMD)
- Mounting: Fixed Type
- Standards: IEC 60947-2, CE Certified
- Applications: Ideal for motor protection, feeder protection, and distribution systems
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | Schneider Electric |
| Product Range | Compact NSX |
| Rated Voltage (Ue) | 415V AC |
| Rated Insulation Voltage (Ui) | 690V AC |
| Rated Frequency | 50/60Hz |
| Terminal Type | Screw Clamp |
Why Choose This Product?
The Schneider Electric NSX100F MCCB offers robust protection with its high breaking capacity and reliable thermal magnetic trip mechanism. Its compact design saves panel space while maintaining superior performance. Suitable for demanding environments, this breaker ensures uninterrupted power distribution with enhanced safety.
Applications
- Industrial control panels
- Commercial building electrical systems
- Motor protection circuits
- Power distribution networks
- HVAC systems
Available at myelectric.in – Your trusted partner for quality electrical components!
