Description:

The Schneider Electric NSX100H is a high-performance molded case circuit breaker designed for superior protection in electrical distribution systems. With a breaking capacity of 70kA, this 3-pole (3P) device ensures reliable circuit protection in demanding industrial and commercial applications.

Key Features:

• Current Rating: 25A
• Breaking Capacity: 70kA at 415V AC
• Number of Poles: 3P (3 Poles)
• Tripping Unit: Micrologic 2.0 MA (Microprocessor-based)
• Mounting: Fixed type
• Standards Compliance: IEC 60947-2
• Applications: Ideal for motor protection, feeder protection, and main circuit protection

Technical Specifications:

• Rated Operational Voltage (Ue): 415V AC
• Rated Insulation Voltage (Ui): 690V AC
• Rated Ultimate Short-circuit Breaking Capacity (Icu): 70kA
• Rated Service Short-circuit Breaking Capacity (Ics): 70kA
• Mechanical Durability: 20,000 operations
• Electrical Durability: 5,000 operations

Why Choose Schneider Electric NSX100H?

The NSX series offers advanced protection features with Micrologic trip units, ensuring precise and reliable operation. The compact design saves panel space while delivering high breaking capacity for enhanced safety.

Applications:

• Industrial power distribution
• Commercial buildings
• Data centers
• Infrastructure projects

Note: For complete system integration, additional accessories like shunt trips, auxiliary contacts, or communication modules may be required.
