Schneider Electric NSX100H 70kA AC 4P3D 63A TMD (C10H6TM063)
Product Description
The Schneider Electric NSX100H is a high-performance molded case circuit breaker designed for superior protection in demanding electrical installations. This 4-pole (4P3D) unit with a 63A current rating and Thermal Magnetic Trip (TMD) offers reliable circuit protection with a breaking capacity of 70kA.
Key Features
- Model: NSX100H
- Part Number: C10H6TM063
- Breaking Capacity: 70kA at 415V AC
- Number of Poles: 4P3D (4 Poles with 3 protected poles)
- Current Rating: 63A
- Trip Unit: Thermal Magnetic (TMD)
- Mounting: Fixed type
- Standards: IEC 60947-2, IS/IEC 60947-2
- Applications: Industrial, commercial and infrastructure installations
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Current (In) | 63A |
| Rated Voltage (Ue) | 415V AC |
| Rated Insulation Voltage (Ui) | 690V |
| Rated Frequency | 50/60Hz |
| Short Circuit Breaking Capacity (Icu) | 70kA at 415V AC |
| Operating Temperature | -25°C to +70°C |
Applications
Ideal for:
- Industrial power distribution
- Commercial buildings
- Data centers
- Infrastructure projects
- HVAC systems
- Motor protection
Why Choose This Product?
- High breaking capacity for enhanced safety
- Reliable thermal magnetic protection
- Compact design saves panel space
- Schneider Electric quality and reliability
- Easy installation and maintenance
Note: Compatible with Schneider Electric accessories for complete system integration.
