Schneider Electric NSX100N 50kA AC 4P3D 25A TMD (C10N6TM025)

Product Overview

The Schneider Electric NSX100N is a high-performance molded case circuit breaker designed for superior protection in electrical installations. This 4-pole (4P) device with 3 protected poles (3D) offers a breaking capacity of 50kA at 415V AC, making it ideal for commercial and industrial applications.

Key Features

• Model: NSX100N
• Current Rating: 25A
• Breaking Capacity: 50kA at 415V AC
• Number of Poles: 4P3D (4 poles with 3 protected poles)
• Trip Unit: Thermal Magnetic (TMD)
• Product Code: C10N6TM025
• Brand: Schneider Electric

Technical Specifications

• Rated Voltage: 415V AC
• Frequency: 50/60Hz
• Mounting: Fixed type
• Standards: IEC 60947-2
• Operating Temperature: -25°C to +70°C

Applications

Ideal for:

• Commercial buildings
• Industrial plants
• Data centers
• Electrical distribution panels
• Motor protection circuits

Why Choose This Product?

• High breaking capacity for superior protection
• Reliable thermal-magnetic trip unit for accurate protection
• Compact design saves panel space
• Schneider Electric quality and reliability
• Easy installation and maintenance

Package Includes

• 1 x Schneider Electric NSX100N 25A Circuit Breaker
• Manufacturer documentation
