Product Description

The Schneider Electric NSXm100B is a high-performance molded case circuit breaker designed for superior protection in electrical distribution systems. This 4P3D (4 Pole 3 Protected) model with 32A rating and Thermal Magnetic Trip (TMD) offers reliable circuit protection with a breaking capacity of 25kA AC.

Key Features:

• Compact Design: Space-saving solution for panel builders
• High Breaking Capacity: 25kA AC interruption rating
• Thermal Magnetic Trip: Provides both overload and short-circuit protection
• Busbar Connection: Ensures secure and efficient power distribution
• 4 Pole Configuration: 3 protected poles + 1 unprotected neutral pole
• 32A Current Rating: Suitable for medium power applications

Applications:

• Commercial buildings
• Industrial power distribution
• Data centers
• HVAC systems
• Electrical panels and switchboards

Technical Specifications:

• Brand: Schneider Electric
• Product Range: NSXm100B
• Number of Poles: 4P3D (4 Pole, 3 Protected)
• Rated Current: 32A
• Breaking Capacity: 25kA AC
• Trip Unit Type: TMD (Thermal Magnetic)
• Connection Type: Busbar
• Standards: IEC 60947-2

This Schneider Electric circuit breaker offers reliable protection and is part of the renowned NSX series known for its quality and durability in electrical protection systems.
