EMS-03 | 3-Phase 4-Wire KWh Meter | Class 1 Accuracy | EAPL Certified
Key Features:
- High Accuracy: Class 1.0 as per IS/IEC Standards
- 3-Phase 4-Wire: Suitable for balanced & unbalanced loads
- LCD Display: Clear energy consumption readings
- MID Approved: Legal for trade measurements
- Wide Voltage Range: 220-240V AC, 50Hz operation
- Impulse Protection: 6kV surge protection
- Tamper Proof: Anti-theft detection mechanism
- Compact Design: DIN rail mountable (4 module)
- Long Life: 10+ years operational lifespan
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model | EMS-03 |
| Type | Static Energy Meter |
| Voltage | 3×230/400V AC |
| Current | 5(60)A, 10(100)A options |
| Accuracy Class | 1.0 |
| Display | Backlit LCD with 8 digits |
| Pulse Output | 1000 imp/kWh (Test Output) |
| Operating Temp | -25°C to +55°C |
| Certification | EAPL, CE, RoHS Compliant |
Applications:
- Commercial establishments
- Industrial power monitoring
- Apartment energy billing
- Solar net metering systems
- Data center power management
Why Choose Our 3-Phase Energy Meter?
The EMS-03 three-phase kWh meter provides precise energy measurement for accurate billing and power monitoring. With EAPL certification and Class 1 accuracy, it’s ideal for commercial and industrial applications where reliable energy tracking is essential. The tamper-proof design ensures billing integrity while the robust construction guarantees long-term performance.
Installation & Support
Easy DIN rail mounting with clear terminal markings. Includes detailed installation manual. Our technical team provides free consultation for bulk orders.
