EZ9F76220 | Easy9 MCB 2P 20A 6000A C Curve – Schneider Electric

Name: EZ9F76220 | Easy9 MCB 2P 20A 6000A C Curve - Schneider Electric - myelectric.in
Brand: Schneider Electric
SKU: EZ9F76220
Price: 557.06 INR
Availability: BackOrder

SKU: EZ9F76220

Original price was: ₹1,211.00.Current price is: ₹557.06. Excl. GST

Dispatch By : 1 Weeks

18 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

The Schneider Electric EZ9F76220 is a miniature circuit breaker (mcb), engineered for reliable circuit protection and isolation in demanding Indian and international installations. Key ratings include 20 A, 2 Poles. Buy the EZ9F76220 | Easy9 MCB 2P 20A 6000A C Curve online at myelectric.in with GST invoice, genuine-product assurance, and fast delivery across India — bulk and worldwide export enquiries welcome.

📋 Technical Specifications

Parameter	Value
Brand	Schneider Electric
Part Number / SKU	EZ9F76220
Category	Miniature Circuit Breaker (MCB)
Current Rating	20 A
Poles	2 Poles
Breaking Capacity	6 kA
Tripping Curve	Curve C
Rated Voltage	230/400V AC
Rated Frequency	50/60 Hz
Magnetic Trip Range	5–10 × In (per IEC 60898-1)
Trip Mechanism	Thermal-magnetic (bimetal overload + electromagnetic short-circuit)
Mounting	35mm DIN rail (EN 60715)
Width	36 mm (2 × 18mm modules)
Electrical Endurance	≥ 20,000 operating cycles (per IEC 60898-1)
Pollution Degree	3 (per IEC 60664-1)
Standard	IS 8828 / IEC 60898-1 (residential) and IEC 60947-2 (industrial)
Certifications	BIS certified, CE marked, RoHS compliant

⚡ Key Features

Protects circuits at 20 A with 6 kA short-circuit breaking capacity — rated for residential and commercial final circuits.
Curve C tripping characteristic — optimised for general-purpose and inductive loads (motors, mixed circuits) — trips magnetically at 5–10× rated current.
2 Poles — protects a single-phase circuit, switching both live and neutral; fits standard 35mm DIN rail in distribution boards.
Thermal-magnetic trip mechanism — bimetal element trips on sustained overload, instantaneous magnetic trip on short-circuit; two independent protection functions in one compact module.
Manufactured to IS 8828 / IEC 60898-1 (residential) and IEC 60947-2 (industrial) — complies with the applicable Indian BIS and IEC international standards for this product category.
BIS certified, CE marked, RoHS compliant — meets Indian regulatory requirements for use in government, commercial, and industrial electrical installations.
Genuine authorised Schneider Electric product — sourced directly from the official distribution network with full manufacturer traceability and warranty.
GST invoice provided for India orders — valid for corporate procurement, government project orders, and public tender supply via myelectric.in.
Worldwide export available — UAE, Singapore, UK, USA, Sri Lanka & more. Contact +91 94814 00316 for bulk pricing and international shipping.
