Product Description

The GV2LE03 from Schneider Electric is a high-quality motor circuit breaker with magnetic protection, rated at 0.4A. Part of the renowned TeSys GV2 range, this compact and reliable device offers optimal protection for your motors and circuits.

Key Features:

• Current Rating: 0.4A
• Type: Magnetic only protection
• Actuation: Toggle switch operation
• Poles: 3 poles
• Breaking Capacity: High breaking capacity for reliable protection
• Mounting: DIN rail mountable (35mm)
• Standards: Complies with IEC/EN 60947-2 standards
• Applications: Ideal for motor protection in industrial and commercial applications

Technical Specifications:

• Rated Insulation Voltage (Ui): 690V AC
• Rated Operational Voltage (Ue): 415V AC
• Thermal-Magnetic Setting: Fixed magnetic setting
• Ambient Temperature: -20°C to +60°C
• Mechanical Durability: 20,000 operations
• Electrical Durability: 10,000 operations

Applications:

Perfect for protecting small motors, pumps, fans, and other electrical equipment where precise magnetic-only protection is required. Commonly used in industrial control panels, HVAC systems, and manufacturing equipment.

Why Choose Schneider Electric GV2 Series?

Schneider Electric’s GV2 series offers reliable motor protection with compact dimensions, easy installation, and maintenance-free operation. The GV2LE03 provides precise magnetic tripping for short-circuit protection without thermal overload protection.
