HTC307 | Humidity + Temperature Controller – Selec

The HTC307 is a versatile and reliable Humidity and Temperature Controller designed by Selec. It is ideal for applications requiring precise control of environmental conditions, such as in greenhouses, storage facilities, laboratories, and industrial processes.

Key Features:

• Dual Display: Simultaneously displays temperature and humidity readings on a clear, easy-to-read LCD screen.
• Wide Measurement Range: Temperature range: -50°C to 150°C (-58°F to 302°F); Humidity range: 0% to 100% RH.
• High Accuracy: Offers precise measurements with temperature accuracy of ±0.5°C and humidity accuracy of ±3% RH.
• Programmable Setpoints: Allows users to set desired temperature and humidity levels for automatic control.
• Relay Outputs: Equipped with relay outputs for controlling external devices such as heaters, coolers, humidifiers, and dehumidifiers.
• Alarm Function: Features high and low alarm settings for both temperature and humidity, ensuring timely alerts for out-of-range conditions.
• Sensor Type: Comes with a high-quality NTC temperature sensor and capacitive humidity sensor for reliable performance.
• Power Supply: Operates on a wide range of power supply options (85-265V AC or 24V DC), making it suitable for various applications.
• Compact Design: Compact and robust design for easy installation and integration into existing systems.
• User-Friendly Interface: Intuitive interface with simple navigation buttons for easy configuration and operation.
• Durability: Built to withstand harsh environments with a durable housing and high-quality components.

Applications:

The HTC307 is suitable for a wide range of applications, including:

• Greenhouses and agricultural environments
• HVAC systems
• Food storage and processing facilities
• Pharmaceutical and laboratory settings
• Industrial process control
• Museums and archives for climate control

Technical Specifications:

Package Includes:

• 1 x HTC307 Humidity + Temperature Controller
• 1 x NTC Temperature Sensor
• 1 x Capacitive Humidity Sensor
• 1 x User Manual

Warranty:

The HTC307 comes with a standard 1-year warranty from the date of purchase, covering manufacturing defects and faulty components.

Product Data Sheet
