HTC206 | 4 Digit Dual Display Humidity + Temperature Controller – Selec

The HTC206 is a high-precision 4-digit dual display humidity and temperature controller designed for accurate monitoring and control of environmental conditions. It is ideal for applications in HVAC systems, greenhouses, laboratories, and industrial processes.

Key Features:

• Dual Display: Simultaneously displays temperature and humidity readings on a 4-digit LED screen.
• High Accuracy: Provides precise measurements with a temperature accuracy of ±0.5°C and humidity accuracy of ±3% RH.
• Wide Measurement Range: Temperature range: -40°C to 120°C (-40°F to 248°F); Humidity range: 0% to 100% RH.
• Programmable Control: Allows setting of temperature and humidity setpoints for automatic control of connected devices.
• Relay Output: Equipped with a relay output for controlling external devices such as heaters, coolers, humidifiers, or dehumidifiers.
• Sensor Type: Comes with a high-quality external sensor for accurate readings.
• Power Supply: Operates on a wide range of power supply options (85-265V AC or 12-24V DC).
• Compact Design: Compact and easy-to-install design suitable for various applications.
• User-Friendly Interface: Simple and intuitive interface for easy configuration and operation.
• Durability: Built to withstand harsh environmental conditions with a robust housing.

Applications:

• HVAC systems
• Greenhouses
• Laboratories
• Industrial processes
• Food storage and processing
• Pharmaceutical storage

Technical Specifications:

Package Includes:

• 1 x HTC206 Controller
• 1 x External Sensor
• 1 x User Manual

Warranty:

The HTC206 comes with a standard 1-year warranty against manufacturing defects.

Product Data Sheet
