MFM376 | LED Multifunction Meter – Selec
The MFM376 is a high-precision LED multifunction meter designed by Selec for accurate measurement and monitoring of electrical parameters. It is ideal for industrial, commercial, and residential applications.
Key Features:
- Measurement Parameters: Measures voltage, current, power (active, reactive, apparent), power factor, frequency, and energy (kWh, kVARh).
- Display: Bright LED display for clear visibility in all lighting conditions.
- Accuracy: High accuracy with ±0.5% for voltage and current, and ±1% for power and energy.
- Input Range: Wide input range for voltage (80-300V AC) and current (0-5A AC).
- Communication: Supports RS485 Modbus RTU communication for remote monitoring and control.
- Mounting: DIN rail mounting for easy installation.
- Dimensions: Compact design with dimensions of 96x96x58 mm.
- Operating Temperature: Operates efficiently in a temperature range of -10°C to +55°C.
- Safety Standards: Complies with IEC 61010-1 safety standards.
- Applications: Suitable for energy management, power monitoring, and load analysis in various setups.
Additional Features:
- Backlit display for low-light environments.
- Programmable CT ratio for flexible current measurement.
- Data logging capability for historical data analysis.
- User-friendly interface for easy configuration.
Applications:
The MFM376 is widely used in:
- Industrial power distribution systems.
- Commercial buildings for energy monitoring.
- Renewable energy systems like solar and wind power plants.
- Residential energy management systems.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Voltage Range | 80-300V AC |
| Current Range | 0-5A AC |
| Accuracy | ±0.5% (Voltage, Current), ±1% (Power, Energy) |
| Display | LED |
| Communication | RS485 Modbus RTU |
| Mounting | DIN Rail |
| Dimensions | 96x96x58 mm |
| Operating Temperature | -10°C to +55°C |
Conclusion:
The MFM376 LED Multifunction Meter by Selec is a reliable and versatile solution for monitoring and managing electrical parameters. Its high accuracy, robust design, and advanced features make it an excellent choice for a wide range of applications.
