Product Description – C10B3TM032

Circuit Breaker – ComPacT NSX100B

Manufacturer: Schneider Electric

Model: C10B3TM032

Type: Circuit Breaker

Series: ComPacT NSX100B

Breaking Capacity: 25kA at 415V AC

Number of Poles: 3

Trip Unit: TMD (Thermal Magnetic Trip Unit)

Rated Current: 32A

Voltage Rating: 415V AC

Application: Suitable for protection against overloads and short circuits in electrical circuits.

Features:

• High breaking capacity of 25kA at 415V AC.
• Thermal magnetic trip unit (TMD) for reliable protection.
• Compact design for easy installation and space-saving.
• 3-pole configuration for three-phase systems.
• Rated current of 32A for medium load applications.
• Compatible with Schneider Electric’s ComPacT NSX series accessories.
• Robust construction for durability and long service life.
• Complies with international standards for safety and performance.

Applications:

• Industrial control panels.
• Commercial buildings.
• Data centers.
• HVAC systems.
• Motor control centers.

Standards Compliance:

• IEC 60947-2
• IEC 60947-1
• CE Marked

Dimensions:

• Width: 53.5 mm
• Height: 88 mm
• Depth: 70 mm

Weight: Approximately 0.8 kg

Environmental Conditions:

• Operating Temperature: -25°C to +60°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 95% at 40°C

Warranty: Standard manufacturer warranty applies.
