Product Description – C10B6TM100

Circuit Breaker – ComPacT NSX100B

Key Features:

• Model: ComPacT NSX100B
• Rated Current: 100A
• Breaking Capacity: 25kA at 415V AC
• Number of Poles: 4 Poles (3D – Neutral not protected)
• Trip Unit: TMD (Thermal Magnetic Trip Unit)
• Voltage Rating: 415V AC
• Application: Suitable for protection against overloads and short circuits in electrical circuits.
• Mounting: Fixed type
• Standards Compliance: IEC 60947-2, IEC 60947-4-1
• Terminal Type: Screw type terminals
• Environmental Conditions: Designed to operate in temperatures ranging from -25°C to +70°C.
• Mechanical Durability: High mechanical endurance with up to 20,000 electrical operations.
• Safety Features: Equipped with a visible contact position indicator and a padlockable handle for enhanced safety.

Additional Information:

The ComPacT NSX100B circuit breaker is part of Schneider Electric’s ComPacT NSX range, known for its compact design and high performance. The TMD trip unit provides reliable protection against overloads and short circuits, making it ideal for a wide range of industrial and commercial applications. The 4-pole configuration with an unprotected neutral ensures flexibility in various electrical systems.

Applications:

• Industrial control panels
• Commercial buildings
• Data centers
• Power distribution systems

Warranty:

Schneider Electric offers a standard warranty period of 24 months from the date of purchase, subject to terms and conditions.

Technical Support:

For technical assistance, contact Schneider Electric’s customer support team or visit their official website for more information.
