Product Description – C16F3TM160

ComPacT NSX160F Circuit Breaker

Model: C16F3TM160

Manufacturer: Schneider Electric

Type: Circuit Breaker

Series: ComPacT NSX

Rated Current: 160A

Number of Poles: 3

Breaking Capacity: 36kA at 415V AC

Trip Unit: TMD (Thermal Magnetic Trip Unit)

Voltage Rating: 415V AC

Mounting: Fixed

Standards: IEC 60947-2, IEC 60947-4-1, IEC 60947-5-1

Application: Suitable for protection and control of electrical circuits in industrial and commercial applications.

Features:

• High breaking capacity of 36kA at 415V AC.
• Thermal magnetic trip unit (TMD) for reliable overload and short-circuit protection.
• Compact design for space-saving installation.
• Fixed mounting type for easy installation.
• Complies with international standards for safety and performance.
• Robust construction for durability in harsh environments.
• Compatible with Schneider Electric’s range of accessories and communication modules.

Dimensions:

• Width: 105mm
• Height: 150mm
• Depth: 70mm

Weight: Approximately 2.5kg

Environmental Conditions:

• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 95% at +40°C

Certifications: CE, UL, CSA, RoHS compliant

Warranty: Standard manufacturer warranty applies.
