LV510317 | EasyPact CVS100B Circuit Breaker
Product Overview
The EasyPact CVS100B is a high-performance circuit breaker designed by Schneider Electric for reliable protection in electrical installations. It features a thermal magnetic trip unit (TM-D) and is rated for 25 kA at 415 VAC with a 100 A current rating. This 4-pole (4P) circuit breaker is ideal for industrial, commercial, and residential applications.
Key Features
- Model: EasyPact CVS100B
- Part Number: LV510317
- Rated Current: 100 A
- Breaking Capacity: 25 kA at 415 VAC
- Trip Unit: Thermal Magnetic (TM-D)
- Number of Poles: 4P (4 Poles)
- Mounting: 3D (Three Dimensions)
- Voltage Rating: 415 VAC
- Standards Compliance: IEC 60947-2
- Application: Suitable for protection against overloads and short circuits in electrical circuits.
Detailed Specifications
| Feature | Specification |
|---|---|
| Rated Current (In) | 100 A |
| Rated Voltage (Ue) | 415 VAC |
| Breaking Capacity (Icu) | 25 kA |
| Trip Unit Type | Thermal Magnetic (TM-D) |
| Number of Poles | 4P |
| Mounting Type | 3D |
| Standards | IEC 60947-2 |
| Application | Overload and short-circuit protection |
Applications
The EasyPact CVS100B circuit breaker is designed for use in a variety of applications, including:
- Industrial control panels
- Commercial buildings
- Residential electrical systems
- Motor protection circuits
- Distribution boards
Benefits
- High breaking capacity ensures reliable protection.
- Thermal magnetic trip unit provides precise overload and short-circuit protection.
- Compact design saves space in electrical panels.
- Complies with international standards for safety and performance.
Disclaimer
Product specifications are subject to change without prior notice. Always refer to the manufacturer’s datasheet for the most accurate and up-to-date information.
