LV540309 | EasyPact CVS400F Circuit Breaker

Product Overview

The EasyPact CVS400F is a high-performance circuit breaker designed by Schneider Electric for reliable protection in electrical installations. It features a thermal magnetic trip unit (TM-D) and is rated for 400 A with a breaking capacity of 36 kA at 415 VAC. This 4-pole (4P) circuit breaker is ideal for industrial and commercial applications.

Key Features

• Model: EasyPact CVS400F
• Rated Current: 400 A
• Breaking Capacity: 36 kA at 415 VAC
• Trip Unit: Thermal Magnetic (TM-D)
• Number of Poles: 4P (4 Poles)
• Mounting: Fixed
• Standards Compliance: IEC 60947-2
• Terminal Type: Screw-type terminals
• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Mechanical Durability: 20,000 operations
• Electrical Durability: 10,000 operations
• Protection Features: Overload and short-circuit protection
• Dimensions: 144 mm (H) x 90 mm (W) x 85 mm (D)
• Weight: Approximately 2.5 kg

Applications

The EasyPact CVS400F is suitable for a wide range of applications, including:

• Industrial control panels
• Commercial buildings
• Power distribution systems
• Motor protection circuits
• HVAC systems

Benefits

• High breaking capacity ensures reliable protection in demanding environments.
• Thermal magnetic trip unit provides precise overload and short-circuit protection.
• Compact design saves space in electrical panels.
• Complies with international standards for safety and performance.
• Durable construction ensures long service life.

Technical Support

For technical assistance or additional information, contact Schneider Electric’s customer support team.
