Product Description – LV540318 | EasyPact CVS400N
Overview
The EasyPact CVS400N is a high-performance circuit breaker designed by Schneider Electric. It is part of the EasyPact CVS range, known for its reliability and efficiency in protecting electrical circuits. This model is specifically designed for industrial and commercial applications, offering robust protection against overloads and short circuits.
Key Features
- Model: EasyPact CVS400N
- Rated Current: 320 A
- Breaking Capacity: 50 kA at 415 VAC
- Trip Unit: Thermal Magnetic TM-D
- Number of Poles: 4P (4 Poles)
- Mounting: 3D (Three Dimensions)
- Standards Compliance: IEC 60947-2
- Application: Suitable for use in industrial and commercial environments for circuit protection.
Detailed Features
Thermal Magnetic Trip Unit (TM-D)
The TM-D trip unit provides reliable protection against both overloads and short circuits. The thermal component protects against overloads by responding to prolonged overcurrents, while the magnetic component provides instantaneous protection against short circuits.
High Breaking Capacity
With a breaking capacity of 50 kA at 415 VAC, the EasyPact CVS400N can handle high fault currents, ensuring the safety and reliability of the electrical installation.
4-Pole Configuration
The 4-pole configuration ensures comprehensive protection for all phases and the neutral, making it suitable for a wide range of applications, including those requiring neutral protection.
3D Mounting
The 3D mounting feature allows for flexible installation in various orientations, providing ease of installation and space optimization in electrical panels.
Robust Construction
Built with high-quality materials, the EasyPact CVS400N is designed to withstand harsh industrial environments, ensuring long-term reliability and performance.
Applications
The EasyPact CVS400N is ideal for use in:
- Industrial plants
- Commercial buildings
- Data centers
- Infrastructure projects
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Current (In) | 320 A |
| Rated Voltage (Ue) | 415 VAC |
| Breaking Capacity (Icu) | 50 kA |
| Trip Unit Type | Thermal Magnetic TM-D |
| Number of Poles | 4P |
| Mounting | 3D |
| Standards | IEC 60947-2 |
Conclusion
The EasyPact CVS400N circuit breaker is a reliable and efficient solution for protecting electrical circuits in demanding environments. With its high breaking capacity, thermal magnetic trip unit, and flexible mounting options, it is an excellent choice for industrial and commercial applications.
