Product Description – LV540316 | EasyPact CVS400N

Circuit Breaker – EasyPact CVS400N

Product Code: LV540316

Manufacturer: Schneider Electric

Series: EasyPact CVS

Rated Current: 400 A

Breaking Capacity: 50 kA at 415 VAC

Trip Unit Type: Thermal Magnetic (TM-D)

Number of Poles: 3P (3 Poles)

Number of Protected Poles: 3d (3 Protected Poles)

Features:

• High Breaking Capacity: 50 kA at 415 VAC ensures reliable protection in demanding electrical environments.
• Thermal Magnetic Trip Unit: Provides both overload and short-circuit protection with precise and reliable operation.
• Compact Design: Space-saving design suitable for a wide range of applications.
• Easy Installation: Designed for quick and easy installation, reducing downtime.
• Durable Construction: Built to withstand harsh conditions, ensuring long-term reliability.
• Versatile Application: Suitable for use in industrial, commercial, and residential settings.
• Compliance: Meets international standards for safety and performance.

Applications:

• Industrial control panels
• Commercial buildings
• Residential complexes
• Power distribution systems
• Motor control centers

Standards and Certifications:

• IEC 60947-2
• UL 489
• CSA C22.2 No. 5

Additional Information:

• Mounting: Fixed
• Termination Type: Screw
• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: Up to 95% RH at 40°C

Warranty: Standard manufacturer warranty applies.

Note: Specifications are subject to change without notice. Please refer to the manufacturer’s datasheet for the most accurate and up-to-date information.

Product PDF
