LC1E40B01M7 | Easy TeSys Contactor

Product Description

The LC1E40B01M7 is a 3-pole (3 NO) contactor from Schneider Electric’s Easy TeSys series. It is designed for AC-3 applications with a maximum voltage of 440 V and a current rating of 40 A. The contactor features a 220 V AC coil, making it suitable for a wide range of industrial and commercial applications.

Key Features

• Type: Contactor
• Series: Easy TeSys
• Number of Poles: 3 (3 NO)
• Rated Operational Voltage (Ue): ≤ 440 V
• Rated Operational Current (Ie): 40 A
• Coil Voltage: 220 V AC
• Application Category: AC-3
• Mounting: Screw mounting
• Terminal Type: Screw terminals
• Mechanical Durability: 10 million operations
• Electrical Durability: 1 million operations
• Ambient Temperature Range: -25°C to +60°C
• Protection Degree: IP20 (finger-safe)
• Dimensions: Compact design for space-saving installation
• Compliance: Meets international standards for safety and performance

Applications

The LC1E40B01M7 contactor is ideal for controlling three-phase motors, heating systems, and other industrial equipment. It is commonly used in:

• Motor control centers
• HVAC systems
• Pumps and compressors
• Conveyor systems
• Industrial automation

Benefits

• High reliability and durability
• Easy installation and maintenance
• Compact design saves space in control panels
• Compatible with a wide range of accessories
• Energy-efficient operation

Technical Support

For technical support, installation guidance, or troubleshooting, please contact Schneider Electric’s customer service or visit their official website.
