LC1E40E7 | Easy TeSys Contactor

Product Overview

The LC1E40E7 is a 3-pole contactor from Schneider Electric’s Easy TeSys series, designed for reliable switching of electrical loads. It is suitable for a wide range of industrial and commercial applications, offering high performance and durability.

Key Features

• Type: 3P (3 NO) – 3 Poles with 3 Normally Open (NO) contacts
• Rated Operational Current (Ie): 40A
• Rated Operational Voltage (Ue): ≤ 440V AC
• Coil Voltage: 48V AC
• Utilization Category: AC-3 (Suitable for squirrel cage motors: starting, stopping)
• Mechanical Durability: Up to 10 million operations
• Electrical Durability: Up to 1 million operations
• Mounting: DIN rail or screw mounting
• Terminal Type: Screw terminals for secure connections
• Environmental Compliance: RoHS compliant, meets international standards
• Safety Standards: IEC/EN 60947-4-1, UL 60947-4-1, CSA C22.2 No. 14

Applications

The LC1E40E7 contactor is ideal for controlling motors, lighting, heating, and other electrical loads in various industries, including manufacturing, HVAC, and automation.

Dimensions and Weight

• Width: 45 mm
• Height: 80 mm
• Depth: 73 mm
• Weight: Approx. 0.35 kg

Additional Information

For more details, refer to the official Schneider Electric product documentation or contact their support team.
