LC1E80004M5WBIN | Easy TeSys Contactor

Product Description

The LC1E80004M5WBIN is an Easy TeSys contactor from Schneider Electric, designed for reliable switching and control of electrical circuits. It features 4 poles (2 Normally Open + 2 Normally Closed) and is suitable for AC-1 applications. With a maximum voltage rating of 415V and a current rating of 110A, this contactor is ideal for industrial and commercial applications.

Key Features

• Type: Contactor
• Poles: 4P (2 NO + 2 NC)
• Application: AC-1
• Voltage Rating: ≤ 415V
• Current Rating: 110A
• Coil Voltage: 415V AC
• Brand: Schneider Electric
• Series: Easy TeSys
• Mounting: Screw Mounting
• Contact Material: Silver Alloy
• Mechanical Durability: High
• Electrical Durability: High
• Operating Temperature: -25°C to +60°C
• Protection Degree: IP20
• Compliance: IEC/EN 60947-4-1 Standards

Applications

The LC1E80004M5WBIN contactor is widely used in:

• Motor Control
• Industrial Automation
• HVAC Systems
• Lighting Control
• Power Distribution

Benefits

• High reliability and durability
• Easy installation and maintenance
• Compact design for space-saving
• Compatible with a wide range of applications
• Complies with international standards

Technical Specifications

Warranty

This product comes with a standard warranty of 2 years from the date of purchase, subject to Schneider Electric’s terms and conditions.
