LC1E80008M5WBIN | Easy TeSys Contactor
Product Overview
The LC1E80008M5WBIN is a high-performance contactor from Schneider Electric’s Easy TeSys series. Designed for industrial and commercial applications, this contactor ensures reliable switching and control of electrical circuits.
Key Features
- Type: 4P (4 Normally Open Contacts)
- Rated Voltage: ≤ 415 V
- Rated Current: 110 A
- Coil Voltage: 415 V AC
- Application Category: AC-1 (Non-inductive or slightly inductive loads)
- Mounting: Screw mounting or snap-on mounting
- Contact Material: Silver alloy for high durability
- Mechanical Life: Up to 10 million operations
- Electrical Life: Up to 1 million operations
- Environmental Compliance: RoHS compliant
- Protection Degree: IP20 (finger-safe design)
- Dimensions: Compact design for space-saving installation
- Terminals: Screw terminals for secure connections
- Accessories: Compatible with auxiliary contacts, timers, and mechanical interlocks
Applications
The LC1E80008M5WBIN is ideal for controlling motors, lighting, heating, and other electrical loads in various industries, including manufacturing, HVAC, and energy management systems.
Benefits
- High reliability and durability
- Easy installation and maintenance
- Wide range of compatible accessories
- Energy-efficient design
- Safe and compliant with international standards
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Operational Current (Ie) | 110 A |
| Rated Operational Power (P) | 45 kW at 400 V AC |
| Coil Power Consumption | 12 VA |
| Operating Temperature Range | -25°C to +60°C |
| Weight | Approx. 0.8 kg |
Compliance and Certifications
- IEC/EN 60947-4-1
- UL 508
- CSA C22.2 No. 14
- CE Marked
Warranty
Schneider Electric offers a standard warranty of 24 months from the date of purchase, subject to terms and conditions.
