METSEEM1220HCL1 – EasyLogic PM1220H Panel Mount Meter

Product Overview

The METSEEM1220HCL1 is a high-performance panel mount meter from Schneider Electric’s EasyLogic PM1220H series. Designed for precise energy monitoring and management, this Class 1 meter is ideal for industrial, commercial, and residential applications. It features an LCD display, RS485 communication, and a robust design for reliable operation.

Key Features

• Class 1 Accuracy: Ensures high precision in energy measurement, compliant with international standards.
• LCD Display: Clear and easy-to-read display for real-time monitoring of electrical parameters.
• RS485 Communication: Supports Modbus RTU protocol for seamless integration with energy management systems.
• Panel Mount Design: Compact and durable design for easy installation in control panels.
• Wide Measurement Range: Measures voltage, current, power, energy, frequency, and power factor.
• Multi-Tariff Functionality: Supports up to 4 tariffs for flexible energy billing.
• Event Logging: Records critical events for troubleshooting and analysis.
• Energy Pulse Output: Provides pulse output for external energy monitoring devices.
• Robust Construction: Built to withstand harsh environments with high resistance to electrical noise.
• Compliance: Meets IEC 62053-21, IEC 62053-22, and IEC 61010-1 standards.

Technical Specifications

Applications

The EasyLogic PM1220H meter is suitable for a wide range of applications, including:

• Energy monitoring in industrial facilities
• Commercial building energy management
• Residential energy consumption tracking
• Sub-metering and load profiling
• Integration with SCADA and BMS systems

Ordering Information

Product Code: METSEEM1220HCL1

Manufacturer: Schneider Electric

Series: EasyLogic PM1220H

Warranty and Support

Schneider Electric offers a standard warranty of 2 years for this product. Comprehensive technical support and documentation are available through their global network.
