LC1D09BD | TeSys D Contactor – Schneider Electric

Product Description

The LC1D09BD is a TeSys D contactor from Schneider Electric, designed for controlling three-phase motors and other electrical loads. It features 3 normally open (NO) contacts, making it suitable for a wide range of industrial applications.

Key Features

• Type: Contactor
• Series: TeSys D
• Number of Poles: 3P (3 NO)
• Rated Operational Voltage (Ue): ≤ 440 V AC
• Rated Operational Current (Ie): 9 A (AC-3)
• Coil Voltage: 24 V DC
• Utilization Category: AC-3
• Mechanical Durability: Up to 10 million operations
• Electrical Durability: Up to 1 million operations
• Mounting: Screw mounting or snap-on mounting
• Terminal Type: Screw terminals
• Dimensions: Compact design for space-saving installation
• Standards: Complies with IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No. 14
• Environmental Compliance: RoHS compliant

Applications

The LC1D09BD contactor is ideal for use in:

• Motor control in industrial machinery
• HVAC systems
• Pump and fan control
• Lighting control systems
• General-purpose switching applications

Additional Information

This contactor is part of the TeSys D range, known for its reliability, durability, and ease of installation. It is designed to operate in harsh environments and provides excellent performance in both low and high-duty applications.

Warranty

Schneider Electric offers a standard warranty on this product. Please refer to the manufacturer’s warranty policy for more details.
