LC1D1506M7 | TeSys D Contactor

Product Description

The LC1D1506M7 is a TeSys D contactor manufactured by Schneider Electric. It is designed for controlling three-phase motors and other high-power electrical loads. This contactor is part of the TeSys D range, known for its reliability and durability in industrial applications.

Key Features

• Type: 3P (3 NO) – 3 Pole, 3 Normally Open contacts
• Rated Operational Current (Ie): 150 A
• Rated Operational Voltage (Ue): ≤ 440 V AC
• Coil Voltage: 220 V AC, 50/60 Hz
• Utilization Category: AC-3 (Squirrel cage motors: starting, switching off)
• Mechanical Durability: Up to 10 million operations
• Electrical Durability: Up to 1 million operations
• Mounting: Screw mounting or snap-on mounting on rail
• Terminal Type: Screw terminals
• Environmental Compliance: RoHS compliant, suitable for use in harsh environments
• Safety Standards: Complies with IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No. 60947-4-1

Applications

The LC1D1506M7 contactor is ideal for use in various industrial applications, including:

• Motor control in manufacturing plants
• HVAC systems
• Pump and fan control
• Compressor control
• Conveyor systems

Dimensions and Weight

• Width: 72 mm
• Height: 130 mm
• Depth: 105 mm
• Weight: Approximately 1.2 kg

Accessories

Compatible accessories include:

• Auxiliary contact blocks
• Mechanical interlocks
• Time delay modules
• Surge suppressors

Additional Information

For more details, refer to the official Schneider Electric product datasheet or contact their customer support.
