LC1K1201E7 | TeSys K Contactor – Schneider Electric
Product Overview
The LC1K1201E7 is a TeSys K contactor from Schneider Electric, designed for reliable and efficient control of electrical circuits. It is suitable for a wide range of industrial and commercial applications.
Key Features
- Type: 3P (3 Pole)
- Rated Operational Voltage (Ue): AC-3 ≤ 440 V
- Rated Operational Current (Ie): 12 A
- Auxiliary Contact: 1 NC (Normally Closed)
- Coil Voltage: 48 V AC
- Mounting: Screw mounting
- Mechanical Durability: Up to 10 million operations
- Electrical Durability: Up to 1 million operations
- Enclosure: IP20 (finger-safe)
- Standards: Compliant with IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No. 14
- Environmental Compliance: RoHS compliant
Applications
The LC1K1201E7 contactor is ideal for controlling motors, lighting, heating, and other electrical loads in various industrial and commercial settings.
Technical Specifications
| Parameter | Value |
|---|---|
| Number of Poles | 3 |
| Rated Power (AC-3) | 5.5 kW at 400 V |
| Coil Power Consumption | 6 VA |
| Operating Temperature Range | -25°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Weight | Approx. 0.3 kg |
Additional Information
For more details, refer to the official Schneider Electric product documentation or contact their customer support.
