LC1K1210E7 | TeSys K Contactor – Schneider Electric
Product Overview
The LC1K1210E7 is a TeSys K contactor from Schneider Electric, designed for reliable switching and control of electrical circuits. It is a 3-pole contactor suitable for AC-3 applications up to 440 V and 12 A. This contactor is equipped with a 1 NO (Normally Open) auxiliary contact and operates with a 48 V AC coil.
Key Features
- Type: TeSys K Contactor
- Number of Poles: 3P (3 Poles)
- Rated Operational Voltage (Ue): Up to 440 V AC
- Rated Operational Current (Ie): 12 A (AC-3)
- Auxiliary Contact: 1 NO (Normally Open)
- Coil Voltage: 48 V AC
- Application: Suitable for AC-3 applications, such as controlling squirrel cage motors.
- Mounting: DIN rail or screw mounting
- Standards Compliance: Meets IEC/EN 60947-4-1 standards
- Durability: High mechanical and electrical durability
- Environmental Resistance: Resistant to dust, humidity, and vibrations
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Thermal Current (Ith) | 12 A |
| Rated Operational Power (P) | 5.5 kW at 400 V AC |
| Coil Power Consumption | Approx. 5 VA |
| Mechanical Life | Up to 10 million operations |
| Electrical Life | Up to 1 million operations |
| Weight | Approx. 0.3 kg |
Applications
The LC1K1210E7 contactor is ideal for use in various industrial and commercial applications, including:
- Motor control in HVAC systems
- Pump and fan control
- Lighting control systems
- Conveyor systems
- Compressors and other machinery
Warranty and Support
Schneider Electric offers a standard warranty on the LC1K1210E7 contactor. For technical support and warranty claims, contact Schneider Electric’s customer service or visit their official website.
