LP1K1210BD | TeSys K Contactor – Schneider Electric
Product Overview
The LP1K1210BD is a TeSys K contactor from Schneider Electric, designed for reliable switching of electrical loads in industrial and commercial applications. It features a 3-pole configuration and is suitable for AC-3 applications up to 440 V and 12 A. The contactor includes 1 normally open (NO) auxiliary contact and is powered by a 24 V DC coil.
Key Features
- Type: TeSys K Contactor
- Poles: 3P (3 Poles)
- Rated Voltage: AC-3 ≤ 440 V
- Rated Current: 12 A
- Auxiliary Contact: 1 NO (Normally Open)
- Coil Voltage: 24 V DC
- Mounting: DIN Rail or Screw Mounting
- Mechanical Life: Up to 10 million operations
- Electrical Life: Up to 1 million operations
- Enclosure: IP20 (Finger-safe design)
- Compliance: IEC/EN 60947-4-1, UL 60947-4-1, CSA C22.2 No. 14
Applications
The LP1K1210BD contactor is ideal for controlling motors, lighting, and other electrical loads in various applications, including:
- Industrial machinery
- HVAC systems
- Pumps and compressors
- Conveyor systems
- Commercial lighting
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Operational Current (Ie) | 12 A (AC-3) |
| Rated Operational Power (Pe) | 5.5 kW (400 V AC-3) |
| Coil Power Consumption | 2.5 W (24 V DC) |
| Operating Temperature Range | -25°C to +60°C |
| Weight | Approx. 0.25 kg |
Additional Information
For more details, including wiring diagrams, installation instructions, and technical support, visit the official Schneider Electric website.
