LC1K0901B7 | TeSys K Contactor – Schneider Electric
Product Overview
The LC1K0901B7 is a TeSys K contactor from Schneider Electric, designed for reliable switching and control of electrical circuits. It is suitable for a wide range of industrial and commercial applications.
Key Features
- Type: Contactor
- Number of Poles: 3P (3 Poles)
- Rated Operational Voltage (Ue): AC-3 ≤ 440 V
- Rated Operational Current (Ie): 9 A
- Auxiliary Contacts: 1 NC (Normally Closed)
- Coil Voltage: 24 V AC
- Mounting: Screw Mounting
- Mechanical Durability: Up to 10 million operations
- Electrical Durability: Up to 1 million operations
- Enclosure: IP20 (Finger-safe)
- Standards: Compliant with IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No. 14
Applications
The LC1K0901B7 contactor is ideal for controlling motors, lighting, heating, and other electrical loads in various environments, including:
- Industrial machinery
- HVAC systems
- Pumps and compressors
- Conveyors and elevators
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Thermal Current (Ith) | 9 A |
| Power Consumption (Coil) | 4.5 VA |
| Operating Temperature Range | -25°C to +60°C |
| Weight | Approx. 0.22 kg |
Dimensions
Compact design with dimensions: 45 mm (W) x 55 mm (H) x 78 mm (D).
Certifications
Complies with international standards and certifications, ensuring safety and reliability.
Warranty
Standard warranty provided by Schneider Electric. Contact the manufacturer or supplier for details.
