51209 | Varlogic PF Controller RT8 step 440V – Schneider Electric

Name: Schneider Electric Varlogic PF Controller RT8 440V | SKU 51209
Brand: Schneider Electric
SKU: 51209
Price: 17086.05 INR
Availability: InStock

SKU: 51209

Original price was: ₹37,969.00.Current price is: ₹17,086.05. Excl. GST

In stock

11 People watching this product now!

Order protection

Buy with complete confidence.

We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.

Buyer protection on every order

Global DeliveryShipped pan-India and to export markets.

On-Time DeliveryPacked and dispatched on schedule.

100% OriginalFrom brand-authorised channels only.

GST InvoiceCompliant, ITC-ready tax invoice.

Secure PaymentEncrypted, trusted payment gateways.

Also included Dedicated account manager Technical support Bulk & business pricing 3-day replacement

Sourced through authorised channels, the Schneider Electric 51209 power factor controller from the EasyLogic range delivers dependable performance for industrial, commercial, and infrastructure applications. Key ratings include 440V AC, Rear face: IP20. myelectric.in stocks the Varlogic PF Controller RT8 step 440V for contractors, panel builders, and project buyers — buy online with GST invoice, or request a bulk quote for domestic supply and export to UAE, Singapore, UK, USA, Sri Lanka and more.

📋 Technical Specifications

Product
Brand	Schneider Electric
Part Number / SKU	51209
Category	Power Factor Controller
Main
Range	EasyLogic
Product name	EasyLogic PFC Controller
Product or component type	Power factor controller
Complementary
Number of step output contacts	8
[Us] rated supply voltage	320…460 V AC 50/60 Hz
Measurement current	50 mA
Operating mode	Manual
Display type	7 segments LED 4-digit
Type of measurement	Power factor
Alarm function	5 last alarms
Input type	Phase to phase Current input CT…10000/5 A
Output type	Free outputs contacts current: 0.3 A 110 V DC Free outputs contacts current: 0.6 A 60 V DC Free outputs contacts current: 1 A 400 V AC 50/60 Hz Free outputs contacts current: 2 A 24 V DC Free outputs contacts current: 2 A 250 V AC 50/60 Hz Free outputs contacts current: 5 A 120 V AC 50/60 Hz
Type of setting	Target cos phi: 0.85 inductive…1
Measurement accuracy	+/- 2 %
Time delay range	10…1800 s 10…1800 s (on reconnection)
Step sequences	Linear 1.1.2.2 1.2.3.4 1.2.4.8 1.2.3.6 1.1.1.1 1.1.2.3 1.2.2.2 1.2.3.3 1.1.2.4 1.2.4.4
Mounting location	Panel In cabinet
Height	143 mm
Width	143 mm
Depth	67 mm
Product weight	0.8 kg
Environment
Standards	EN 61010-1 IEC 61326 IEC 61000-6-4 IEC 61000-6-2
IP degree of protection	Rear face: IP20 Front face: IP41 conforming to IEC 60429
Ambient air temperature for operation	0…55 °C
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	8.500 cm
Package 1 Width	18.700 cm
Package 1 Length	23.000 cm
Package 1 Weight	1.092 kg
Unit Type of Package 2	S03
Number of Units in Package 2	6
Package 2 Height	30.000 cm
Package 2 Width	30.000 cm
Package 2 Length	40.000 cm
Package 2 Weight	7.194 kg
Unit Type of Package 3	P06
Number of Units in Package 3	48
Package 3 Height	75.000 cm
Package 3 Width	60.000 cm
Package 3 Length	80.000 cm
Package 3 Weight	64.988 kg
Contractual warranty
Warranty (in months)	18

⚡ Key Features

440V AC operating voltage — compatible with standard LV distribution voltages used in Indian industrial installations.
Manufactured to IS/IEC 60947, IS 8828 (MCBs), IS 13947, IEC 61439 (DBs) — complies with Indian BIS and IEC international safety standards.
BIS certified, CE marked, RoHS compliant — meets Indian regulatory requirements for use in government, commercial, and industrial electrical installations.
Genuine authorised Schneider Electric product — sourced directly from the official distribution network with full manufacturer traceability and warranty.
GST invoice provided for India orders — valid for corporate procurement, government project orders, and public tender supply via myelectric.in.
Worldwide export available — UAE, Singapore, UK, USA, Sri Lanka & more. Contact +91 94814 00316 for bulk pricing and international shipping.
