900VPR-2-300/600V | 3Ø-Voltage Protection Relay

Product Overview

The 900VPR-2-300/600V is a 3-phase voltage protection relay designed to monitor and protect electrical systems from voltage-related issues. It is suitable for use in systems with a line-to-line voltage of 480V.

Key Features

• Voltage Range: 300/600V AC
• Phase Configuration: 3-Phase
• Rated Voltage: 480V (L-L)
• Protection Functions:
  • Overvoltage Protection
  • Undervoltage Protection
  • Phase Sequence Protection
  • Phase Loss Protection
  • Phase Asymmetry Protection
• Adjustable Settings: User-configurable voltage thresholds and time delays
• Display: LED or LCD display for real-time voltage monitoring and fault indication
• Communication: Optional communication interface for remote monitoring and control (e.g., Modbus, RS485)
• Mounting: DIN rail mounting for easy installation
• Enclosure: Compact and robust design suitable for industrial environments
• Certifications: Compliant with international standards (e.g., CE, UL, RoHS)

Applications

The 900VPR-2-300/600V is ideal for use in various applications, including:

• Industrial power distribution systems
• Motor protection circuits
• Generator protection
• Renewable energy systems
• HVAC systems

Technical Specifications

Warranty

The product comes with a standard warranty of 2 years from the date of purchase, covering manufacturing defects.
