TC538CX – Dual Bright Display, High Power Relay/SSR Output – Selec
The TC538CX is a high-performance temperature controller designed for precise temperature regulation in various industrial and commercial applications. It features a dual bright display, high power relay/SSR output, and a range of advanced features to ensure accurate and reliable temperature control.
Key Features:
- Dual Bright Display: The TC538CX features a dual bright LED display that shows both the setpoint and the current temperature simultaneously, ensuring easy monitoring and control.
- High Power Relay/SSR Output: Equipped with a high power relay or solid-state relay (SSR) output, the TC538CX can handle high current loads, making it suitable for a wide range of applications.
- Wide Temperature Range: The controller supports a wide temperature range, allowing it to be used in various environments and applications.
- PID Control: The TC538CX utilizes advanced PID (Proportional-Integral-Derivative) control algorithms to maintain precise temperature control, minimizing fluctuations and ensuring stability.
- Multiple Input Types: The controller supports multiple input types, including thermocouples (J, K, T, E, R, S, B, N) and RTDs (Pt100, Pt1000), providing flexibility for different temperature sensing requirements.
- Alarm Function: The TC538CX includes an alarm function that can be configured to trigger based on high or low temperature limits, ensuring timely alerts in case of deviations from the setpoint.
- Auto-Tuning: The auto-tuning feature automatically adjusts the PID parameters to optimize control performance, reducing the need for manual tuning.
- Compact Design: The compact and robust design of the TC538CX makes it easy to install and integrate into existing systems.
- User-Friendly Interface: The intuitive interface and easy-to-navigate menu make the TC538CX simple to set up and operate, even for users with limited technical expertise.
- Durable Construction: Built with high-quality materials, the TC538CX is designed to withstand harsh industrial environments, ensuring long-term reliability and performance.
Applications:
The TC538CX is ideal for a wide range of applications, including:
- Industrial ovens and furnaces
- Plastic molding machines
- Food processing equipment
- HVAC systems
- Laboratory equipment
- Heat treatment processes
Technical Specifications:
| Parameter | Specification |
|---|---|
| Display | Dual bright LED display |
| Output | High power relay/SSR output |
| Temperature Range | -200°C to 1800°C (depending on sensor type) |
| Input Types | Thermocouples (J, K, T, E, R, S, B, N), RTDs (Pt100, Pt1000) |
| Control Algorithm | PID control with auto-tuning |
| Alarm | High/Low temperature alarm |
| Power Supply | 85-264V AC, 50/60Hz |
| Dimensions | 96mm x 96mm x 112mm |
| Weight | Approx. 400g |
Conclusion:
The TC538CX is a versatile and reliable temperature controller that offers precise control, robust construction, and a user-friendly interface. Its advanced features and wide range of applications make it an excellent choice for industries requiring accurate temperature regulation.
