PID500 | PID, Universal Input, Analog/Relay/SSR Output – Selec
The PID500 is a versatile and high-performance PID controller designed for precise temperature and process control. It supports universal input, making it compatible with a wide range of sensors, and offers multiple output options including analog, relay, and SSR (Solid State Relay) outputs.
Key Features
- Universal Input: Compatible with various sensor types including thermocouples (J, K, T, E, R, S, B, N), RTDs (Pt100, JPt100), and analog signals (0-20mA, 4-20mA, 0-5V, 1-5V).
- Multiple Output Options: Supports analog output (4-20mA, 0-10V), relay output, and SSR output for flexible control of different types of actuators.
- Advanced PID Control: Provides precise control with auto-tuning, manual tuning, and programmable PID parameters for optimal performance.
- Dual Display: Features a dual-line display showing both the process value (PV) and setpoint (SV) simultaneously for easy monitoring.
- Programmable Setpoints: Allows setting of up to 16 setpoints with ramp/soak profiles for complex control sequences.
- Alarm Functions: Equipped with multiple alarm options including high, low, deviation, and sensor break alarms for enhanced safety and process control.
- Communication Options: Supports RS485 communication with Modbus RTU protocol for integration with SCADA systems and other devices.
- Compact Design: Compact and robust design suitable for panel mounting in various industrial environments.
- User-Friendly Interface: Intuitive menu navigation and easy-to-use interface for quick setup and operation.
- Wide Power Supply Range: Operates on a wide range of power supply voltages (85-265V AC/DC) for global compatibility.
Applications
The PID500 is ideal for a wide range of applications including:
- Temperature control in industrial furnaces, ovens, and kilns
- Process control in chemical, pharmaceutical, and food processing industries
- HVAC systems for precise climate control
- Plastic molding and extrusion processes
- Laboratory equipment and research applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Types | Thermocouples (J, K, T, E, R, S, B, N), RTDs (Pt100, JPt100), Analog (0-20mA, 4-20mA, 0-5V, 1-5V) |
| Output Types | Analog (4-20mA, 0-10V), Relay, SSR |
| Control Algorithm | PID with auto-tuning and manual tuning |
| Display | Dual-line, 4-digit LED display |
| Setpoints | Up to 16 programmable setpoints with ramp/soak profiles |
| Alarms | High, Low, Deviation, Sensor Break |
| Communication | RS485 with Modbus RTU protocol |
| Power Supply | 85-265V AC/DC |
| Dimensions | 96x96mm (panel cutout 92x92mm) |
| Mounting | Panel mount |
