600VPR-1-130/320V-CE | Voltage Protection Relay for 220V (L-N) – Selec
Product Description
The 600VPR-1-130/320V-CE is a high-performance voltage protection relay designed to safeguard electrical systems by monitoring and controlling voltage levels. It is specifically designed for 220V (L-N) systems and ensures reliable protection against overvoltage, undervoltage, and phase failure conditions.
Key Features
- Voltage Range: 130V to 320V AC
- Rated Voltage: 220V AC (L-N)
- Protection Functions: Overvoltage, Undervoltage, and Phase Failure Protection
- Adjustable Settings: User-configurable voltage thresholds and delay times
- Display: LED indicators for status and fault detection
- Output Relay: 1 Changeover (CO) relay with 5A, 250V AC rating
- Mounting: DIN rail mounting for easy installation
- Compliance: CE certified, ensuring compliance with European safety standards
- Operating Temperature: -20°C to +60°C
- Dimensions: 90mm x 35mm x 65mm (L x W x H)
- Weight: Approximately 150g
Applications
The 600VPR-1-130/320V-CE is ideal for use in a variety of applications, including:
- Industrial automation systems
- HVAC systems
- Power distribution panels
- Renewable energy systems
- Commercial and residential electrical systems
Technical Specifications
| Parameter | Value |
|---|---|
| Input Voltage | 220V AC (L-N) |
| Voltage Range | 130V to 320V AC |
| Output Relay | 1 CO, 5A, 250V AC |
| Operating Temperature | -20°C to +60°C |
| Mounting | DIN Rail |
| Dimensions | 90mm x 35mm x 65mm |
| Weight | 150g |
Warranty
This product comes with a standard 1-year warranty from the date of purchase.
