XT543-N | SINGLE DISPLAY, 9 TIME RANGES, 48X48MM – Selec
Product Overview
The XT543-N is a high-precision, single-display time relay designed for a wide range of industrial and commercial applications. With its compact 48x48mm size, it offers versatile timing functions across 9 different time ranges, making it an ideal choice for automation and control systems.
Key Features
- Compact Design: 48x48mm size for easy integration into control panels.
- Single Display: Clear and easy-to-read display for precise time monitoring.
- 9 Time Ranges: Offers flexibility with 9 selectable time ranges to suit various applications.
- High Accuracy: Ensures precise timing for reliable operation.
- Wide Voltage Range: Compatible with a broad range of input voltages for versatile use.
- Durable Construction: Built to withstand harsh industrial environments.
- Easy Installation: Simple mounting and wiring for quick setup.
- LED Indicators: Visual status indicators for easy monitoring of relay operation.
- Multiple Timing Modes: Supports on-delay, off-delay, and other timing modes.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 48x48mm |
| Display Type | Single Display |
| Time Ranges | 9 Selectable Ranges |
| Input Voltage | 24V AC/DC, 110V AC, 230V AC |
| Contact Rating | 5A @ 250V AC |
| Operating Temperature | -10°C to +55°C |
| Mounting | Panel Mount |
| Certifications | CE, RoHS Compliant |
Applications
The XT543-N is suitable for a variety of applications, including:
- Industrial automation
- Motor control
- Lighting control
- HVAC systems
- Pump control
- Conveyor systems
Warranty
The XT543-N comes with a standard 1-year warranty against manufacturing defects.
