XTC262 | MULTIFUNCTION DIGITAL TIMER + PROGRAMMABLE COUNTER – Selec
The XTC262 is a versatile and high-performance multifunction digital timer and programmable counter designed for a wide range of industrial and commercial applications. It combines advanced timing and counting functionalities in a compact and user-friendly design, making it an ideal solution for automation, process control, and time-based operations.
Key Features:
- Multifunction Operation: Supports multiple timing and counting modes, including ON delay, OFF delay, interval, cyclic, and more.
- Programmable Counter: Offers up to 6-digit counting capability with a wide range of counting modes, including up, down, and bidirectional counting.
- High Accuracy: Equipped with a precise quartz crystal oscillator for accurate timing and counting operations.
- Dual Display: Features a dual 6-digit LED display for easy monitoring of time and count values simultaneously.
- Wide Voltage Range: Operates on a wide input voltage range (12-240V AC/DC), making it suitable for various power supply configurations.
- Multiple Output Options: Provides relay, transistor, and SSR output options for flexible integration with different control systems.
- Compact Design: Compact and DIN rail mountable design for easy installation in control panels.
- User-Friendly Interface: Intuitive front-panel controls and programming buttons for easy setup and operation.
- Wide Temperature Range: Operates reliably in a wide temperature range (-10°C to +55°C), ensuring performance in harsh environments.
- High Reliability: Built with high-quality components for long-term reliability and durability.
Applications:
The XTC262 is suitable for a variety of applications, including:
- Industrial automation
- Process control systems
- Packaging machinery
- Conveyor systems
- Lighting control
- HVAC systems
- Energy management systems
Technical Specifications:
| Parameter | Specification |
|---|---|
| Input Voltage | 12-240V AC/DC |
| Display | Dual 6-digit LED |
| Timing Range | 0.1 seconds to 9999 hours |
| Counting Range | 0 to 999999 |
| Output Types | Relay, Transistor, SSR |
| Operating Temperature | -10°C to +55°C |
| Mounting | DIN Rail |
| Dimensions | 48mm x 48mm x 78mm |
Warranty:
The XTC262 comes with a standard 1-year warranty against manufacturing defects.
