006920141 | SensTempDuct STD300-300 0/100 – Schneider Electric
Original price was: ₹22,686.00.₹13,157.88Current price is: ₹13,157.88. Excl. GST
Dispatch By : 9 Weeks
Dispatch By : 9 Weeks
20
People watching this product now!
Order protection
Buy with complete confidence.
We back each order with genuine supply, on-time dispatch and GST or commercial invoicing as required.
Global DeliveryShipped pan-India and to export markets.
On-Time DeliveryPacked and dispatched on schedule.
100% OriginalFrom brand-authorised channels only.
GST InvoiceCompliant, ITC-ready tax invoice.
Secure PaymentEncrypted, trusted payment gateways.
Also included
Dedicated account manager
Technical support
Bulk & business pricing
3-day replacement
Specifications
| Main | |
|---|---|
| Range of product | STD300 |
| Product or component type | Temperature sensor |
| Type of measurement | Temperature |
| Device application | Duct |
| Analogue output type | 4…20 mA |
| IP degree of protection | IP65 |
| location | Plant room |
| Mounting support | Duct |
| Depth | 45 mm |
| Height | 66 mm |
| Net weight | 0.125 kg |
| Width | 85 mm |
| Output type | Analog output |
| Standards | EN 50082-1 EN 50081-1 |
| Colour | Black and green |
| Ambient air temperature for operation | -20…70 °C: amplifier |
| Sensor type | Temperature transmitter temperature |
| Targeted region | Asia Pacific. Europe |
| Complementary | |
| Material | Aluminium: mounting flange PA (polyamide): connection box Stainless steel: immersion tube |
| Time constant | 52000 ms 3 l/min 72000 ms 1.5 l/min |
| [Us] rated supply voltage | 15…36 V DC |
| Connections – terminals | Wire (24 AWG…18 AWG) |
| Length | 300 mm for side probe |
| Diameter | 6 mm probe: |
| Measurement accuracy | 0…25 °C +/- 0.3 °C |
| Environment | |
| Product certifications | CE |
| Measurement range | 0…100 °C |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 38.8 cm |
| Package 1 Width | 9.2 cm |
| Package 1 Length | 7.2 cm |
| Package 1 Weight | 247.6 g |
| Contractual warranty | |
| Warranty (in months) | 24 |
